Gabion Wire Mesh

Short Description:


Made of Heavy zinc coated wire or PVC coated wire, used for Guide Rivers, to protect and conserve
riverbanks, to build and consolidate dykes, build retaining walls for roads, rail lines, and any kind of works where earth retaining is required.


Product Detail

Product Tags

Opening

(mm)

Wire Diameter

(mm)

Wire Diameter(PVC Coated)

Inner/outside(mm)

Strands
60×80 2.0-2.8 2.0/3.0-2.5/3.5 3
80×100 2.0-3.2 2.0/3.0-2.8/3.8 3
80×120 2.0-3.2 2.0/3.0-2.8/3.8 3
100×120 2.0-3.4 2.0/3.0-2.8/3.8 3
100×150 2.0-3.4 2.0/3.0-2.8/3.8 3
120×150 2.0-4.0 2.0/3.0-3.0/4.0 3

Gabion Box

Length Width Height Diaphragm Volume Tolerance
2.0m 1.0m 0.3m 1 0.6m3
3.0m 1.0m 0.3m 2 0.9m3
4.0m 1.0m 0.3m 3 0.2m3
2.0m 1.0m 0.5m 1 1.0m3 L+/-3%
3.0m 1.0m 0.5m 2 1.5m3 W+/-5%
4.0m 1.0m 0.5m 3 2.0m3 H+/-5%
1.0m 1.0m 0.5m 0 1.0m3
1.0m 1.0m 1.0m 0 1.5m3
2.0m 1.0m 1.0m 1 2.0m3
3.0m 1.0m 1.0m 2 3.0m3
4.0m 1.0m 1.0m 3 4.0m3
